BRT HARTNER D

BRT HARTNER D

Usable for waste paper, household waste, commercial and mixed construction waste, organic waste, etc.

Product Highlights

  • Loosened up and even material feeding to sorting and recovery units
  • Minimal risk of entangling with strings, long films and tapes
  • Efficiency boost of as much as 20% compared to common feeding methods


The BRT HARTNER D Feed and Metering Hoppers are designed for the continuous and evenfeeding of a wide variety of materials.

ecological technik product image

Versatile in Use

The Feed Hoppers / Metering Hoppers are preferably used to feed sorting and processing plants with waste paper, packaging waste, household waste, commercial waste and organic material. They are also used to process special materials such as glass, electronic waste, tire shreds, shredder heavy material or rejects.


ecological technik product image
ecological technik product image
ecological technik product image

Maintenance

All service-relevant components are located outside the hopper interior
→ Easily and quickly accessible
→ No emptying necessary

Access to the bunker via maintenance door with safety switch

Low maintenance and cleaning effort


ecological technik product image

Various Sizes

The Feed and Metering Hopper is designed in several sizes in order to accommodate to different conveying capacities and feeding intervals.


ecological technik product image

Process Reliability

The volume flow control is sensor-supported and fully automatic. This guarantees greater process reliability and at the same time ensures higher throughputs. The maintenance-friendly design ensures high machine availability.


Technical Data BRT HARTNER D


  •
  • Working Width (mm)
  • Number of Push Planks (Pieces)
  • Filling Height (mm)
  • Total Height (mm)
  • Extension in Steps of (mm)
  • Total Length max. (mm)
  • Volume (m3)
  • Drive Power (kW)
  • Weight (t) from


  • D 17
  • 1,700
  • 12
  • 1,900
  • 2,500
  • 2,000
  • 17,900
  • 13 - 46
  • 11 - 33
  • 7


  • D 23
  • 2,300
  • 16
  • 1,900
  • 2,500
  • 2,000
  • 23,900
  • 18 - 90
  • 11 - 33
  • 9
